Verizon Cell Phone Signal Booster

Any 2G network system, including GSM900, DCS1800, CDMA850, PCS1900, and others, can have its verizon cell phone signal boosters from Raygnal adjusted to amplify it.

Description

Any 2G network system, including GSM900, DCS1800, CDMA850, PCS1900, and others, can have its verizon cell phone signal boosters from Raygnal adjusted to amplify it. Applications include areas with poor signals, such as the country, the mountains, or the villages.



However, how to judge the quality of a cell phone signal booster? Here are some factors can be considered as shown below:



1. Gain: The gain of a cell phone signal booster determines how much it can amplify the incoming signal. A good quality signal booster should have a high gain to ensure that it can improve the signal strength significantly.



2. Frequency range: The frequency range of a cell phone signal booster will determine the types of signals it can boost. A good quality signal booster should be designed to work with a wide range of frequencies to ensure that it can handle all types of signals.



3. Signal strength: A cell phone signal booster should be able to boost the signal strength significantly to provide better call clarity and faster data speeds.



4. Interference: A good quality signal booster should be designed to reduce interference from other wireless devices in the area.



5. Durability: A signal booster should be well-built to withstand harsh weather and temperature conditions. It should also be designed to last for many years.



6. Installation: A good quality signal booster should be easy to install and come with instructions that are easy to understand.



7. Compliance: A signal booster should comply with all relevant regulations and be certified by the appropriate authorities.



By considering these factors, you can judge the quality of a cell phone signal booster and determine if it is suitable for your needs.



Features



1. Compact size with stable performance.

2. MGC available for both UL & DL.

3. AGC Alarms if interference occurs.

4. Auto shut off once severe self-oscillation.

5. LCD display to make operation easily.

6. Cost-effective for practical solutions.

7. Antenna isolation testing automatically.

8. High voice quality and fast data transmission.

9. Simple Structure & Easy installation.



Specs



Parameters

Uplink

Downlink

Frequency Range

LTE700

788~798MHz

758~768MHz

LTE800

832~ 862MHz

791~ 821MHz

LTE1800

1710 ~ 1755MHz

2110 ~ 2155MHz

LTE2600

2550~2570MHz

2620~2690MHz

Operation Bandwidth (-3dB)

Wide Band

Maximum Gain

75dB

80dB

Output Power

23dBm

30dBm

MGC (Manual Gain Control)

31dB range/1dB step

AGC (Automatic Gain Control)

≧25dB

Noise Figure

≤ 6dB

VSWR

≦2.0

Group Delay

≤1μs

LED Alarm

Power LED

DC ON/OFF

AGC LED

Red, ALC≥10dB

ISO LED

Red, ALC≥25dB, RF stop working

RF Connector

N-Female

Impedance

50Ω

Power Consumption

5W

Power Supply

Input: AC 110~240V; Output: DC 5.9V/3A

Operating Temperature

-10℃~50℃

Environment Conditions

IP30

Dimensions (Lx W x H)

128*170*65mm

Weight (N.W)

≤1.5KG
