Homemade Cell Phone Signal Booster

By boosting the signal strength and lowering the likelihood of dropped calls and subpar audio, a homemade cell phone signal booster can considerably enhance call quality.

Description

By boosting the signal strength and lowering the likelihood of dropped calls and subpar audio, a homemade cell phone signal booster can considerably enhance call quality. Cellular data speeds can rise with a stronger signal, enabling quicker downloads, quicker streaming, and more dependable browsing.



A cell phone signal booster can help increase the range of the cellular signal if you live or work in an area with patchy service, improving coverage at your house or place of business. A signal booster can also be a more affordable option to increase the signal strength and coverage than subscribing to a more expensive data or voice plan with better coverage.



The majority of GSM signal boosters are simple to install and don't require much technical expertise. Even choices that don't need to be installed are available, making them useful for usage in vehicles and while traveling.



Features



1. Compact size with stable performance.

2. MGC available for both UL & DL.

3. AGC Alarms if interference occurs.

4. Auto shut off once severe self-oscillation.

5. LCD display to make operation easily.

6. Cost-effective for practical solutions.

7. Antenna isolation testing automatically.

8. High voice quality and fast data transmission.

9. Simple Structure & Easy installation.



Specs



Parameters

Uplink

Downlink

Frequency Range

UMTS800

830-840MHz

875-885MHz

WCDMA2100

1920~ 1980MHz

2110~ 2170MHz

AWS1700

1710 ~ 1755MHz

2110 ~ 2155MHz

PCS1900

1850-1910MHz

1930-1990MHz

Operation Bandwidth (-3dB)

Wide Band

Maximum Gain

65dB

70dB

Output Power

15dBm

20dBm

MGC (Manual Gain Control)

31dB range/1dB step

AGC (Automatic Gain Control)

≧25dB

Noise Figure

≤ 6dB

VSWR

≦2.0

Group Delay

≤1μs

LED Alarm

Power LED

DC ON/OFF

AGC LED

Red, ALC≥10dB

ISO LED

Red, ALC≥25dB, RF stop working

RF Connector

N-Female

Impedance

50Ω

Power Consumption

5W

Power Supply

Input: AC 110~240V; Output: DC 5.9V/3A

Operating Temperature

-10℃~50℃

Environment Conditions

IP30

Dimensions (Lx W x H)

128*170*65mm

Weight (N.W)

≤1.5KG

product-800-800
product-800-800
product-800-800
product-800-800
product-800-800
product-800-800
