A 4G signal repeater, also called cell phone repeater, is a 2 way (bi-directional) amplifier. A booster amplifies the signal from the cell tower (downlink) to your cell phone, and also amplifies the signal from you cell phone to the remote cell tower (uplink). Hence it is a bi-directional (two way) amplifier.

Cell phone boosters work across a range of frequencies, typically for North America the two primary ranges are the 800 MHz Band (nominally based around 850MHz) and the 1900 MHz band, Other countries have slightly different frequencies but operate in both a high band and low band range.

Generally speaking, but not exclusively, the lower bands are used in long distance cell phone coverage, while the higher bands are used in urban environments. Your cell phone will automatically switch between one of the two bands without you knowing it.

Features

1. Compact size with stable performance.

2. MGC available for both UL & DL.

3. AGC Alarms if interference occurs.

4. Auto shut off once severe self-oscillation.

5. LCD display to make operation easily.

6. Cost-effective for practical solutions.

7. Antenna isolation testing automatically.

8. High voice quality and fast data transmission.

9. Simple Structure & Easy installation.

Specs

Parameters		Uplink	Downlink
Frequency Range	LTE700	788~798MHz	758~768MHz
	LTE800	832~ 862MHz	791~ 821MHz
	LTE1800	1710 ~ 1755MHz	2110 ~ 2155MHz
	LTE2600	2550~2570MHz	2620~2690MHz
Operation Bandwidth (-3dB)		Wide Band
Maximum Gain		60dB	65dB
Output Power		10dBm	15dBm
MGC (Manual Gain Control)		31dB range/1dB step
AGC (Automatic Gain Control)		≧25dB
Noise Figure		≤ 6dB
VSWR		≦2.0
Group Delay		≤1μs
LED Alarm	Power LED	DC ON/OFF
	AGC LED	Red, ALC≥10dB
	ISO LED	Red, ALC≥25dB, RF stop working
RF Connector		N-Female
Impedance		50Ω
Power Consumption		5W
Power Supply		Input: AC 110~240V; Output: DC 5.9V/3A
Operating Temperature		-10℃~50℃
Environment Conditions		IP30
Dimensions (Lx W x H)		12817065mm
Weight (N.W)		≤1.5KG
