4G LTE signal booster is a device that amplifies or boosts weak cellular signals to improve network coverage and data speed. It captures the existing signals from the base station, amplifies them, and rebroadcasts them to areas where the signal is weak or nonexistent. LTE signal boosters enhance network quality, especially for users located far from the cellular tower or in areas with obstacles blocking signals, such as tall buildings or remote locations.
A 4G signal booster mostly comprises an external antenna, an amplifier, and an indoor antenna.
The installation of the LTE signal booster depends on the configuration of the booster kit you have purchased. Here are some general guidelines to follow while installing an LTE signal booster:
1. Find the best location: The external antenna should be placed outdoors in the best possible location with maximum signal strength. A clear line of sight to the cell tower is ideal.
2. Mounting the antenna: The external antenna should be mounted securely to avoid any mechanical disturbance. A vertical mounting angle is the best practice in most cases.
3. Cabling: The coaxial cable connects the external antenna to the amplifier. It should be kept as short as possible to minimize signal loss. Do not damage the cable while passing it through the walls or the ceiling.
4. Installing the amplifier: The amplifier should be installed indoors near an electrical outlet, which will power it. Keep it away from direct sunlight, heat, or moisture. Connect the indoor antenna to the amplifier through the coaxial cable.
5. Testing: Once you have installed everything, test the signal strength and quality with your device. Adjust the outdoor and indoor antenna positions if necessary to get the best signal.
Overall, the LTE signal booster is an excellent solution for people facing low signal issues in their homes, offices, or vehicles.
Features
1. MGC available for both UL & DL.
2. AGC Alarms if interference occurs.
3. Auto shut off once severe self-oscillation.
4. LCD display to make operation easily.
5. Cost-effective for practical solutions.
6. Antenna isolation testing automatically.
7. High voice quality and fast data transmission.
8. Good Heat-dissipation.
Specs
|
Parameters |
Uplink |
Downlink |
|
|
Frequency Range |
LTE800 |
832 ~ 862MHz |
791 ~ 821MHz |
|
CDMA800 |
824-849MHz |
869-894MHz |
|
|
GSM&EGSM |
880 ~ 915MHz |
925 ~ 960MHz |
|
|
DCS |
1710 ~ 1785MHz |
1805 ~ 1880MHz |
|
|
PCS |
1850-1910MHz |
1930-1990MHz |
|
|
WCDMA |
1920 ~ 1980MHz |
2110 ~ 2170MHz |
|
|
LTE2600 |
2500~2570MHz |
2620 ~ 2690MHz |
|
|
Operation Bandwidth (-3dB) |
Wide Band |
||
|
Maximum Gain |
65dB |
70dB |
|
|
Output Power |
15dBm |
20dBm |
|
|
MGC (Manual Gain Control) |
31dB range/1dB step |
||
|
AGC (Automatic Gain Control) |
≧25dB |
||
|
Spurious Emission |
9KHz~1GHz |
≦-36dBm |
|
|
1GHz~12.75GHz |
≦-30dBm |
||
|
Noise Figure |
≤ 6dB |
||
|
VSWR |
≦2.0 |
||
|
Group Delay |
≤1μs |
||
|
LED Alarm |
Power LED |
DC ON/OFF |
|
|
AGC LED |
Red, ALC≥10dB |
||
|
ISO LED |
Red, ALC≥25dB, RF stop working |
||
|
RF Connector |
N-Female |
||
|
Impedance |
50Ω |
||
|
Power Consumption |
5W |
||
|
Power Supply |
Input: AC 110~240V; Output: DC 5.9V/3A |
||
|
Operating Temperature |
-10℃~50℃ |
||
|
Environment Conditions |
IP30 |
||
|
Dimensions (Lx W x H) |
128*170*65mm |
||
|
Weight (N.W) |
≤1.9KG |
||
